Max Tube Fittings stands out as a top manufacturer and supplier of Stainless Steel 316 Hydraulic Fittings in Delhi, India. We specialize in precision-engineered solutions tailored for hydraulic systems across a variety of industries. SS 316, an austenitic stainless steel grade enriched with molybdenum, offers exceptional corrosion resistance, especially when compared to SS 304, making it ideal for chlorides and marine environments. Our hydraulic fittings are crafted for durability and leak-proof performance, even in high-pressure applications, ensuring dependable operation in critical systems. With our advanced manufacturing standards and robust mechanical properties, Max Tube Fittings delivers SS 316 Hydraulic Fittings that promise long-lasting performance, safety, and efficiency in demanding industrial settings.
Stainless Steel 316 Hydraulic Fittings are composed of chromium (16–18%), nickel (10–14%), and molybdenum (2–3%), which significantly boost their corrosion resistance and durability. They boast a minimum tensile strength of 515 MPa and a yield strength of 205 MPa, along with impressive elongation properties that ensure resilience in high-pressure hydraulic systems. The inclusion of molybdenum enhances resistance to pitting and crevice corrosion, particularly in environments rich in chlorides. With outstanding toughness, ductility, and fatigue resistance, SS 316 Hydraulic Fittings provide secure, leak-proof connections, making them a reliable choice for long-term use in challenging conditions.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | SS 316 ,SS 316L |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
| TEMPERATURE | STAINLESS STEEL 316 – (-60*C TO 400*C) |
| APPLICATIONS & INDUSTRIES | CONSTRUCTION EQUIPMENTS , DRILLING PLATFORMS, HYDRO POWER PLANTS , MACHINE TOOLS , RAILWAY TECHNOLOGY , SHIPBUILDING , WIND TUBRINE , MOBILE HYDRAULIC EQUIPMENT , MINNING , STATIONARY HYDRAULIC EQUIPMENT, INDUSTRIAL HYDRAULICS, INJECTION MOULDING MACHINERY , ALUMINUM DIE-CASTING MACHINERY, SINTERING MACHINERY, STEEL MILLS, HYDRAULIC PRESSES, PAPER PROCESSING MOBILE HYDRAULICS, BUILDING MACHINERY, AGRICULTURAL FORESTRY, LIFTING & MATERIAL HANDLING EQUIPMENT |
| MATERIAL DESIGNATOR | STAINLESS STEEL – ASTM A 276 , ASTM 182 |
Grade | Mn | C | S | Mo | N | Si | P | Cr | Ni | |
316 | Minimum | – | – | – | 2.00 | – | – | 0 | 16.0 | 10.0 |
Maximum | 2.0 | 0.08 | 0.03 | 3.00 | 0.10 | 0.75 | 0.045 | 18.0 | 14.0 | |
316H | Minimum | 0.04 | 0.04 | – | 2.00 | – | 0 | – | 16.0 | 10.0 |
Maximum | 0.10 | 0.10 | 0.03 | 3.00 | – | 0.75 | 0.045 | 18.0 | 14.0 |
Grade | Elong (% in 50mm) min | Yield Str 0.2% Proof (MPa) min | Tensile Str (MPa) min | Hardness | |
Rockwell B (HR B) max | Brinell (HB) max | ||||
316 | 40 | 205 | 515 | 95 | 217 |
316H | 40 | 205 | 515 | 95 | 217 |
Grade | British | Euronorm | UNS No | SS | JIS | ||
European Standards | British Standards | DIN No | Name | ||||
316 | 58H, 58J | 316S31 | 1.4401 | X5CrNiMo17-12-2 | S31600 | 2347 | SUS 316 |
316H | – | 316S51 | – | – | S31609 | – | – |
Contact us to get a quick quote for your requirement.
Stainless steel 316 hydraulic fittings are widely used in applications requiring excellent corrosion resistance. Especially in marine, chemical processing, oil and gas, petrochemical applications and as resistant to chloride and chemicals a its high durability makes it ideal for marine environments, salt marshes and coastal habitats . These materials are also suitable for food and beverage processing, medical devices and water treatment. Where cleanliness and durability are important In addition they perform well in high temperature and pressure conditions, and provide stainless steel 316 hydraulic. Fittings are a reliable choice for connecting pipe and tubing in demanding hydraulic systems.
Please feel free to contact us if you need any further information or for enquiry.
