Max Tube Fittings is a reliable manufacturer and supplier of Hastelloy Hydraulic Fittings based in Delhi, India. They specialize in providing high-performance solutions tailored for demanding fluid handling systems. Crafted from Hastelloy, a superalloy made of nickel, molybdenum, and chromium, these fittings boast exceptional resistance to pitting, stress corrosion cracking, and harsh environments, whether oxidizing or reducing. Engineered for leak-proof and dependable connections, Hastelloy Hydraulic Fittings deliver outstanding durability and performance even under high-pressure conditions. With their superior mechanical strength and corrosion resistance, they find extensive use in industries like chemical processing, marine, offshore, petrochemical, and power generation, where traditional materials often fall short against aggressive chemicals and tough operating conditions.
Hastelloy Hydraulic Fittings are mainly made up of nickel, with notable amounts of molybdenum and chromium, along with small quantities of elements like tungsten, cobalt, and iron. This unique composition grants them impressive resistance to hydrochloric acid, sulfuric acid, and other corrosive substances. On the mechanical side, these fittings offer a tensile strength of around 690 MPa and a yield strength of about 310 MPa, showcasing excellent toughness and fatigue resistance. They remain stable even under extreme temperatures and pressures, ensuring a long service life. Their capability to function effectively in both oxidizing and reducing environments makes them a trusted choice for highly corrosive hydraulic applications.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | HASTELLOY C276, HASTELLOY C22, HASTELLOY B2 |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
| Hastelloy C276 | Ni | C | Mo | Mn | Si | Fe | P | S | Co | Cr |
| Balance | 0.010 Max | 15.00 – 17.00 | 1.00 Max | 0.08 Max | 4.00 – 7.00 | 0.04 Max | 0.03 Max | 2.5 Max | 14.50 – 16.50 | |
| Hastelloy C22 | Balance | 0.010 Max | 12.5 – 14.5 | 0.50 Max | 0.08 Max | 2 – 6 | 0.02 Max | 0.02 Max | 2.5 Max | 20 – 22. |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | |
|---|---|---|---|---|---|
| C22 | 8.69 G/Cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| C276 | 8.89 G/Cm33 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40% |
| B2 | 9.2 G/Cm3 | 1370 °C (2550 °F) | Psi – 1,15,000 , MPa –760 | Psi – 52,000 , MPa – 350 | 40% |
| B3 | 9.2 G/Cm3 | 1370 °C (2550 °F) | Psi – 1,15,000 , MPa –760 | Psi – 52,000 , MPa – 350 | 40% |
| C4 | 8.64 G/Cm3 | 1350-1400 °C | 783 | 365 | 55% |
| Hybrid BC1 | 8.83 G/Cm³ | 1343 – 1443°C | 725 | 310 | 40% |
| X | 8.22 G/Cm³ | 1355°C | 655 MPa | 240 MPa | 35% |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Hastelloy C22 | N06022 | 2.4602 | – | NiCr21Mo14W | NW 6022 | – | – |
| Hastelloy C276 | N10276 | 2.4819 | – | NiMo16Cr15W | NW 0276 | – | ХН65МВУ |
Contact us to get a quick quote for your requirement.
Hastelloy Hydraulic Fittings are widely used in applications where exceptional corrosion resistance and durability are required. They are ideal for chemical plants, for handling strong acids, chlorides and other corrosive liquids. These materials are used in oil and gas exploration, offshore drilling and refinery sites because of their ability to withstand harsh and high-pressure environmental conditions In the petrochemical industry they ensure transferable contacts reliable in extreme temperature piping systems. In addition, Hastelloy Hydraulic Fittings are used in power generation, marine applications, and pharmaceutical applications, where maintaining integrity under extreme conditions is critical to efficient operation.
Please feel free to contact us if you need any further information or for enquiry.
