Duplex Stainless Steel Condensate Pots

Home > Duplex Steel> Duplex Stainless Steel Condensate Pots

Max Tube Fittings is a reliable manufacturer and supplier of Duplex Stainless Steel Condensate Pots based in Delhi, India. We pride ourselves on delivering top-notch solutions for precise measurement and dependable fluid control systems. Crafted from high-quality Duplex Steel grades like S31803 and S32205, these condensate pots are expertly designed to gather and cool condensate before it reaches instrumentation, ensuring accuracy and safety within the system. With exceptional corrosion resistance, impressive mechanical strength, and outstanding durability, they thrive in tough environments. Their sturdy build and leak-proof performance make them ideal for applications in power generation, oil & gas, chemical processing, and marine industries.

Duplex Stainless Steel Type A Condensate Pots with 2 Ports Manufacturer Delhi, Duplex Stainless Steel Type B Condensate Pot with Red Oxide Coated Dealer Delhi, S31803 Duplex Stainless Steel Condensate Pots Type C Supplier Delhi, 2205 Duplex Stainless Steel Type A Condensate Pot Exporter In India, Duplex Stainless Steel Type B Condensate Pots with 3 Ports Manufacturer India, Duplex Stainless Steel Type C Condensate Pot with Galvanized Plating Delhi, India.

Duplex Stainless Steel Condensate Pots feature a unique dual-phase structure, consisting of about 50% ferrite and 50% austenite, which gives them an excellent blend of strength and resistance to corrosion. With a composition that includes 21–23% chromium, 4.5–6.5% nickel, and 2.5–3.5% molybdenum, they effectively resist chloride-induced corrosion, pitting, and crevice attack. On the mechanical side, they boast a tensile strength of around 620 MPa and a yield strength of about 450 MPa, along with remarkable toughness even in low temperatures. These attributes guarantee reliable operation, a long service life, and superior performance in demanding instrumentation and process industries.

Duplex Stainless Steel Condensate Pots Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Sizing Of Duplex Stainless Steel Condensate Pots

P NPT – F	Capacity (Internal Vol.0)cm 3±5%	Pressure Rating PSIG	T mm	L mm	B mm
1/4”	150	1800	2.05	135	50.08
1/4”	300	1800	2.05	225	50.08
1/4”	400	1800	2.05	290	50.08
1/4”	500	1800	2.05	350	50.08
1/4”	1000	1800	4.06	275	88.09
1/4”	2250	1800	5.02	435	120
1/4”	3785	1800	5.02	680	120
1/2”	1000	1800	4.06	275	88.09
1/2”	2250	1800	5.02	435	102
1/2”	3785	1800	5.02	680	102
3/4”	1000	1800	4.06	275	88.09
3/4”	2250	1800	5.02	435	102
3/4”	3785	1800	5.02	680	102

Types of Duplex Stainless Steel Condensate Pots

Duplex Stainless Steel Type A Condensate Pot with Zinc Plating Price in Delhi, DSS Type B Condensate Pots Supplier in Delhi, 2205 Duplex Stainless Steel Type C Condensate Pot Manufacturer in Delhi, Duplex Stainless Steel Type A Condensate Pot with Galvanized Plating Manufacturer & Price in India, Duplex Stainless Steel Condensate Pot Type B Supplier in India, Duplex Stainless Steel Type C Condensate Pot with Red Oxide Coated In Delhi, India.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Duplex Stainless Steel Condensate Pots in Delhi, India

At Max Tube Fittings, We are proud to be the largest supplier, manufacturer, and exporter of Duplex Stainless Steel Condensate Pots in Delhi, India Our cutting-edge solutions cater to all your piping needs. With state-of-the-art production facilities strategically located in the India, we maintain a vast inventory of over 16,000 tons of premium-quality materials, ensuring we have the stock readily available to meet your demands.

Duplex Stainless Steel Condensate Pots Uses

Duplex Stainless Steel Condensate Pots are used in high-pressure steam and condensate systems to collect and manage condensate, ensuring smooth flow and preventing water hammer. They are widely employed in industries such as oil and gas, petrochemical, power generation, and chemical processing, where resistance to corrosion and stress is critical. Their robust construction and excellent mechanical properties make them ideal for applications in harsh environments, where they effectively protect sensitive instrumentation and piping systems by separating condensate from gases and ensuring accurate pressure readings.
