Max Tube Fittings stands out as a top manufacturer and supplier based in Delhi, India, specializing in high-quality Titanium Ball Valves that excel in demanding and corrosive environments. Crafted from premium titanium alloys, including commercially pure titanium and titanium Grade 5 (Ti-6Al-4V), these valves are not only lightweight but also boast remarkable corrosion resistance and an impressive strength-to-weight ratio. Designed with precision to guarantee leak-free operation and a long lifespan, these ball valves are perfect for industries like marine, offshore, aerospace, chemical processing, and desalination, where reliability and durability in harsh conditions are crucial.
The construction of Titanium Ball Valves involves titanium alloys that offer a unique combination of low density and excellent mechanical properties. Alloys such as Grade 2 and Grade 5 deliver exceptional tensile and yield strength while also providing superior resistance to seawater, chlorides, and oxidizing chemicals. These valves maintain outstanding stability across a broad temperature range, high fatigue resistance, and excellent fracture toughness, making them ideal for critical applications. Their sturdy design, precise machining, and corrosion-resistant materials ensure reliable performance and a long service life, even in challenging situations where traditional materials might not hold up.
| STANDARD | ASTM B367, API 600/BS1414, API 598/BS EN 12266-1, ASME B 16.10, ASME B 16.5, ASME B 16.25, ASME B 16.34 |
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| THREAD | NPT, BSPP, BSPT, JIC, METRIC, UNF |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| FUNCTION | 2 WAY, 3 WAY, 4 WAY, 5 WAY, |
| PRESSURE RATING | 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI |
| SEAL RING MATERIAL | PTFE, PVDF, DELRIN, PEEK, GRAPHITE |
| STANDARD | ISO , DIN , ANSI , API , ASME , AWWA , MSS , |
| MEDIA | HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL |
| MEDIA TEMPERATURE | (-120* C TO 500*C )RANGE AS PER PRESSURE |
| BODY TYPE | BAR STOCK |
| PACKING DETAILS | BOX PACKING, WOODEN PALLET |
| APPLICATION | MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS, |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Grade2 | 3.7035 | R50400 |
Contact us to get a quick quote for your requirement.
Titanium Ball Valves are popular in various industries that need lightweight, strong, and corrosion-resistant solutions for flow control. They find extensive use in chemical processing plants, offshore and marine settings, desalination facilities, aerospace systems, oil & gas operations, and power generation units. Their capability to manage corrosive fluids, seawater, and extreme temperatures makes them a dependable choice for maintaining operational efficiency and safety. With their exceptional durability and resistance to aggressive substances, Titanium Ball Valves offer long-lasting, low-maintenance solutions for critical fluid handling and processing needs.
