Titanium Tube Fittings

Home > Titanium > Titanium Tube Fittings

Max Tube Fittings is a leading manufacturer and supplier of Titanium Tube Fittings in Delhi, India, providing high-quality, corrosion-resistant solutions for different industries. These fittings are designed to be strong, leak-proof, and durable in extreme conditions for the long term. Max Tube’s titanium tube fittings are designed to international standards and are available in different configurations and sizes to fit a large number of industrial applications. With an emphasis on accuracy and quality, the company operates in industries such as chemical processing, marine, oil & gas, and power generation, offering customized solutions and prompt delivery to fulfill customer requirements and ensure operational reliability.

Titanium Instrumentation Tube Fittings Supplier in Delhi, Titanium Double Ferrule Tube Fittings Price List in Delhi, Titanium Back Ferrule Manufacturer in Delhi, Titanium Single Ferrule Fittings In India, Titanium Bulkhead Union, Titanium Ferrule Fittings Exporter in Delhi, Titanium Instrumentation Fittings Manufacturer in India, Titanium Compression Tube Fittings in Delhi, India.

Max Tube Titanium Tube Fittings are constructed using Titanium Grade 2 and Grade 5 alloys. Grade 2 provides average strength (tensile strength ~344 MPa) and superior corrosion resistance, whereas Grade 5 (Ti-6Al-4V) has higher strength (~895 MPa), heat resistance, and fatigue life. Grade 2 is more ductile and weldable, and Grade 5 is best suited for high-stress applications. Grade 2 and Grade 5 are both light, biocompatible, and resistant to severe chemicals and elevated temperatures, ensuring their safety for high-performance fluid and gas transfer systems.

Titanium Tube Fittings Specifications

Material Test Certificates (MTC) for Tube Fitting as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175
Specifications	ASTM B366 / ASME SB366
Size	1/16 in. to 2 in. & 2mm to 50 mm.
Dimensional Range	1/16 to 2 inches (imperial); 2 to 50 mm (metric)
Working Pressures	Upto 2000 to 6000 PSI
Thread Type	NPT – ASME B1.20.1, SAE AS71051 \| ISO/BSP Parallel – ISO 228 \| ISO/BSP Tapered – ISO 7, BS EN 10226-1 \| SAE (Unified) – ASME B1.1
End Connections	NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters
Types	Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories
Equivalent To	SWAGELOK, PARKER, DK-LOK, HOKE
Max Working Pressure	8MPa \| 1200psi Depending on The Tubing Material
Working Temperature	-40°C—250°C \| -40°F—482°F Depending on The Tubing Material
Configurations	Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End
Tube Fitting uses & application	Compression tube fitting to connect two imperial tubes (or fractional tubes), two metric tubes or, also, the connection of a metric tube at one end and a fractional/imperial tube at the other end in Petroleum, Power, Chemical, Construction, Gas, Metallurgy, Shipbuilding etc Tube Fittings useful for their extreme temperature and pressure capabilities for high/low temperatures applications, and their compatibility with aggressive fluids, compression fittings can be seen in systems varying from gas lines in refineries, plumbing etc.

Titanium Tube Fittings Chemical Composition

Grade	Ti	C	Fe	H	N	O	Al	V
Titanium Tube Fittings	99.2 min	0.1 max	0.3 max	0.015 max	0.03 max	0.25 max	–	–

Titanium Tube Fittings Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Titanium Tube Fittings	4.5 g/cm3	1665 °C (3030 °F)	Psi – 49900 , MPa – 344	Psi – 39900 , MPa – 275	20 %

Top Titanium Tube Fittings Manufacturing Company in Delhi

At Max Tube Fittings, we are the largest supplier, manufacturer, and exporter of Titanium Tube Fittings in Delhi, India. Our advanced manufacturing facilities, strategically located in the India, allow us to provide high-quality solutions tailored to your specific requirements. With a substantial inventory of over 16,000 tons of top-grade stainless steel materials, we are well-equipped to meet your needs promptly. Our commitment to excellence and efficiency ensures that we consistently maintain available stock to support your demands.

Types of Titanium Tube Fittings

Titanium Tube Fittings Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS
Titanium Tube Fittings	3.7035	R50400

Titanium Bulkhead Union, Titanium Alloy Tube To Union, Titanium Instrumentation Tube Fittings Price in Delhi, Titanium Male Branch Tee Supplier in Delhi, Titanium Bulk Head Female Connector Manufacturer in Delhi, Titanium Single Ferrule Tube Fittings Price in India, Titanium Male Run Tee Supplier And Manufacturer in India, Titanium Male Elbow In Delhi, India.

Largest Manufacturer and Supplier of Titanium Tube Fittings in Delhi, India

At Max Tube Fittings, we are proud to be the largest supplier, manufacturer, and exporter of Titanium Tube Fittings in Delhi, India. Our cutting-edge solutions cater to all your piping needs. With state-of-the-art production facilities strategically located in the India, we maintain a vast inventory of over 16,000 tons of premium-quality materials, ensuring we have the stock readily available to meet your demands.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Titanium Tube Fittings Uses

Titanium Tube Fittings are widely applied in industries like chemical processing, desalination, marine, aerospace, and oil & gas applications. Due to their corrosion resistance, they are the best choice for conveying corrosive or reactive fluids. In marine usage, they are resistant to seawater corrosion, whereas in aerospace applications, they provide weight reduction without sacrificing strength. Power plants and nuclear plants depend on them for pressure stability over a long period. These valves are also ideal for biomedical and pharma processes because they are non-magnetic and non-toxic, eliminating any risk of contamination during operations. Their superior sealing efficiency and resistance to stress corrosion cracking increase system integrity and security.
