Max Tube Fittings is a well-known manufacturer and supplier that is located in Delhi, India. They are specially involved in quality duplex steel hydraulic fittings. These fittings by virtue of their exceptional strength and ability to resist corrosion work reliably under harsh environmental conditions and this is why they are the best when it comes to various industrial uses such as oil, gas, petrochemical use, and marine works. Our products We provide a wide variety of Duplex steel hydraulic fitting which is of high performance and life. Select us when you need a High strength and Efficient solution to the problems of high demand hydraulic systems.
Duplex steel hydraulic fittings are a balanced alloy of chromium, nickel, molybdenum and nitrogen, to provide superior corrosion resistance and strength An excellent mechanical performance, with tensile strength of 620-800MPa and yield strength of 450-550MPa giving high pressure cutting, tells us that the materials are surrounded because of good quality the materials do not only show good resistance to pitting, crevice corrosion and stress corrosion cracking but also is excellent under extreme conditions. Duplex steel hydraulic fittings are highly strength and hardness and have a great weld ability as well as cost effectiveness and apt to use in intricate industrial uses and applications.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | DUPLEX 2205 |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | 1 BAR TO 700 BAR |
| SIZE RANGE | 6 MM TO 42 MM |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH |
ELEMENT | DUPLEX 2205 | DUPLEX 31803 |
|---|---|---|
NI | 4.50 – 6.50 | 4.50 – 6.50 |
C | 0.030 max | 0.030 max |
MN | 2.00 max | 2.00 max |
P | 0.030 max | 0.030 max |
S | 0.20 max | 0.020 max |
SI | 1.00 max | 1.00 max |
CR | 21.0 – 23.0 | 22.0 – 23.0 |
MO | 2.50 – 3.50 | 3.0 – 3.5 |
N | 0.08 – 0.20 | 0.14 – 0.20 |
FE | 63.54 min | 63.72 min |
| Grade | YS (MPa) | UTS (MPa) | % Elongation | Hardness(BHN) |
| 31803 | 450 min. | 620 min. | 25 min. | 293 max. |
| 2205 | 450 min. | 655 min. | 25 min. | 293 max. |
| Density (Kg.m-1) | 7810 |
| Magnetic Permeability | <50 |
| Young’s Modulus (N/mm2) | 190 x 10^3 |
| Specific Heat, 20°C (J.Kg-1.°K-1) | 400 |
| Specific Electrical Resistance, 20°C (µO.m) | 0.85 |
| Thermal conductivity, 20°C | 15 |
| Mean coefficient of thermal expansion | 11 x 10^-6 |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Duplex 2205 Plate | 1.4462 / 1.4462 | UNS S31803 / UNS S32205 |
Contact us to get a quick quote for your requirement.
Duplex steels are popularly utilized in form of hydraulic fittings that need high strength and corrosion rates. They are perfect in offshore oil and gas operations, in which water of high pressure is worked in and they are resistant to corrosion by seawater. These fillers in the chemical industry provide long lasting stability with the acids and other strong chemicals. It is applied to the desalination plants, in the power production and the petrochemical sector, where reliability is clear in harsh conditions. Furthermore, the steel duplex hydraulic fittings are also applied on marine products, pulp and paper productions, and fire fighting products where watertight connection is required at industrial domains with high efficiency.
Please feel free to contact us if you need any further information or for enquiry.
