Max Tube Fittings is a reputable company producing Copper Hydraulic Fittings in Delhi India. It is identified with its quality and reliability. The Copper Hydraulic fittings are built to provide superior operations in various hydraulic fittings at ease and its connection is also secure, high water placements and good corrosion resistance and thermal conductivity ensures its performance in oil and gas, automobiles or in construction or any other industries. We adheres the customer satisfaction, which involves meeting the needs of the customers through customized solutions and excellent service delivery.
Copper hydraulic fittings are hygienic as the high purity usually contains 99 per cent or more copper and may be strengthened and given an added degree of corrosion resistance with a little phosphorus added. These fittings have very good mechanical properties. Their versatility (resistance to corrosion and oxidation and low weight) as well as high tensility (up to 210 MPa) and excellent ductility make them applicable in a number of services such as plumbing and HVAC systems as well as those involving water systems to ensure reliability and efficiency in diverse industries.
| DESIGN STANDARD | DIN 2353/ ISO 8434-1 |
| MATERIAL | COPPER |
| SERIES | LL- LOW PRESSURE , L- MEDIUM PRESSURE, S- HIGH PRESSURE |
| WORKING PRESSURE | (LOW) LL SERIES – 100 BAR |
| (MEDIUM)L SERIES – 100 BAR TO 500 BAR | |
| (HEAVY)S SERIES – 200 BAR TO 800 BAR | |
| SIZE RANGE | LL SERIES – 4LL TO 12LL |
| L SERIES – 6L TO 42L | |
| S SERIES – 6S TO 38S | |
| CONNECTIONS | TUBE TO TUBE , TUBE TO MALE THREAD , TUBE TO FEMALE THREAD , TUBE TO BUTT WELD , TUBE TO SOCKET WELD , TUBE TO JIC 37* , TUBE TO 24* CONE, TUBE TO SWIVEL END , TUBE TO ADJUSTBALE STANDPIPE |
| WELD NIPPLE TO MALE THREAD , WELD NIPPLE TO FEMALE THREAD , WELD NIPPLE TO BUTT WELD , WELD NIPPLE TO SOCKET WELD , WELD NIPPLE TO 24* CONE , WELD NIPPLE TO 37* JIC , WELD NIPPLE TO SWIVEL | |
| BODY TYPE | FORGED, BAR STOCK |
| SURFACE | NATURAL FINISH |
| TEMPERATURE | COPPER – (-60*C TO 175*C) |
| STANDARD | WERKSTOFF NR. | UNS |
| Copper | 1786 | C12200 |
Chemical Requirements: | |||||
| Copper Pipe (Incl. Silver) | 99.85% Min. | ||||
| Phosphorus | 0.013 to 0.5% | ||||
| Total Impurities | 0.06% Max. | ||||
| Density | 8.89 g/cm3 |
| Melting Point | 1370 °C (2500 °F) |
| Tensile Strength | Psi – 1,15,000 , MPa – 790 |
| Yield Strength (0.2%Offset) | Psi – 52,000 , MPa – 355 |
| Elongation | 40 % |
| Condition | Tensile strength N/mm2 | % Elongation on 5.65 A Min. | ||||
| Annealed | 200-250 | 40 | ||||
| Half Hard | 250 Min | 30 | ||||
| As Manufactured | 280 Min | |||||
Contact us to get a quick quote for your requirement.
Copper hydraulic fittings have found their way in most applications because they are efficient and corrosion resistant. In plumbing, secure connections are paved to the plumbing systems to make them durable to operate in. HVAC systems increase transfer of water efficiency, as well as cool and heat systems optimally by using copper insulations. Such features are applied to the automotive industry in improvement of the performance of hydraulic braking systems and power steering mechanisms. In addition to this their weight and endurance qualifies them to be used within hydraulic systems in order to maintain seal in the connection and also offer safe use in rugged surroundings.
Please feel free to contact us if you need any further information or for enquiry.
