Max Tube Fittings stands out as a trusted manufacturer and supplier of Bulkhead Union Elbow fittings, crafted to ensure secure and leak-proof connections in piping and tubing systems. These fittings are specifically designed to connect tubing at a 90° angle through a panel or barrier, allowing for efficient flow redirection while providing essential structural support. With precision threading and machining, they guarantee strong sealing performance. Made from materials like stainless steel, brass, carbon steel, copper, nickel alloys, and special grades, Bulkhead Union Elbows are perfect for demanding applications that require durability, reliability, and resistance to pressure and corrosion.
Bulkhead Union Elbow fittings are known for their exceptional leak-tight performance and resistance to vibration, even in high-pressure situations. Their 90° angled design is perfect for compact systems where space is at a premium. They allow for easy installation through panels or equipment walls while ensuring a secure connection for the tubing. With impressive mechanical strength, precise dimensions, and resistance to corrosion, these fittings are both reusable and long-lasting. Available in a variety of sizes, pressure ratings, and materials, Bulkhead Union Elbows promise reliable service in critical hydraulic, pneumatic, and instrumentation systems.
| Mcneil part no. | Equivalent Part no. Type 1 | Equivalent part no Type 2 | ODT-ØT(INCHES) | C | BODY HEX F | ODT-ØT1(INCHES) | Ø E | D | L | NUT HEX W | L1 |
| 1-BUD | -100-61 | 1BC1 | 1/16 | 0.43 | 5/16 | 1/16 | 0.05 | 0.34 | 0.84 | 5/16 | 1.24 |
| 2-BUD | -200-61 | 2BC2 | 1/8 | 0.60 | 7/16 | 1/8 | 0.09 | 0.50 | 1.50 | 7/16 | 2.02 |
| 3-BUD | -300-61 | 3BC3 | 3/16 | 0.63 | 9/16 | 3/16 | 0.12 | 0.54 | 1.59 | 7/16 | 2.11 |
| 4-BUD | -400-61 | 4BC4 | 1/4 | 0.70 | 5/8 | 1/4 | 0.19 | 0.60 | 1.03 | 9/16 | 2.27 |
| 5-BUD | -500-61 | 5BC5 | 5/16 | 0.73 | 11/16 | 5/16 | 0.25 | 0.64 | 1.81 | 5/8 | 2.39 |
| 6-BUD | -600-61 | 6BC6 | 3/8 | 0.76 | 3/4 | 3/8 | 0.28 | 0.66 | 1.87 | 11/16 | 2.45 |
| 8-BUD | -810-61 | 8BC8 | 1/2 | 0.86 | 7/8 | 1/2 | 0.41 | 0.90 | 2 | 7/8 | 2.80 |
| 10-BUD | -1010-61 | 10BC10 | 5/8 | 0.86 | 1-1/16 | 5/8 | 0.50 | 0.96 | 2.06 | 1 | 2.86 |
| 12-BUD | -1210-61 | 12BC12 | 3/4 | 0.86 | 1-3/16 | 3/4 | 0.63 | 0.96 | 2.31 | 1-1/8 | 3.11 |
| 14-BUD | -1410-61 | 14BC14 | 7/8 | 0.86 | 1-3/8 | 7/8 | 0.72 | 1.02 | 2.53 | 1-1/4 | 3.33 |
| 16-BUD | -1610-61 | 16BC16 | 1 | 1.04 | 1-5/8 | 1 | 0.88 | 1.23 | 2.81 | 1-1/2 | 3.77 |
At Max Tube Fittings, we are the leading supplier, manufacturer, and exporter of Bulkhead Union Elbow in Delhi, India. Our state-of-the-art manufacturing facilities, strategically located in the India, empower us to provide high-quality solutions tailored to your specific requirements. With an extensive inventory of various premium materials, we are well-equipped to meet your needs efficiently. Our dedication to excellence and operational efficiency ensures we consistently maintain available stock, making us your trusted partner for reliable Union Cross fittings in various applications.
Max Tube Fittings is a leading supplier and stockist of premium Bulkhead Union Elbow in Delhi, India. Our products are widely utilized across various industries, recognized for their strength, durability, and reliable performance in connecting multiple pipe sections. We are committed to delivering exceptional service and ensuring high levels of customer satisfaction. Our advanced manufacturing techniques set us apart in the fittings industry, enabling us to consistently provide top-quality Union Cross fittings while effectively addressing the unique requirements of our customers.
Contact us to get a quick quote for your requirement.
Bulkhead Union Elbows are widely used in various applications due to their versatility and reliability. In marine environments, they facilitate secure pipe connections for water and fuel systems, ensuring leak-free operation. In aquaculture, they are crucial for connecting tanks and water circulation systems, promoting efficient water management. These fittings are also commonly found in industrial settings, enabling quick changes in piping direction while maintaining strong connections under pressure. Additionally, they are ideal for plumbing systems in residential and commercial buildings, where space optimization and effective flow control are essential.
