Max Tube Fittings is a premier manufacturer and supplier of Union Cross Fittings in Delhi, India, providing top–performing, leak-tight connections for intricate piping systems. The Union Cross is used to join four tubes in a cross layout for effective fluid or gas distribution in different directions. Precision-engineered with these fittings, easy assembly, high dimensional accuracy, and corrosion resistance are guaranteed. Offered in metals like stainless steel, titanium, or zirconium, Max Tube‘s Union Cross fittings are well-suited for stringent applications in chemical processing, instrumentation systems, power plants, and hydraulic circuits wherein reliability and multi-directional flow are crucial.
Union Cross Fittings come in Titanium Gr 2, Gr 5, Stainless Steel (SS 316/304) and Zirconium 702. Titanium Gr 2 provides ~344 MPa tensile strength and superior corrosion resistance while Gr 5 provides superior strength (~895 MPa). Zirconium 702 provides superior acid resistance and tensile strength comparable to Gr 2. All the materials are light, corrosion-resistant, and thermally stable. The fittings are fatigue–resistant, non–magnetic, and vibration– and pressure-fluctuation-stable for maintenance-free and secure operation in aggressive fluid and gas piping systems.
| UNION TEE | |||||||||||
| TUBE OD | THREAD UN / UNF | S | L | D | PART NO. | ||||||
| mm | inch | N | mm | mm | mm | ||||||
| 6 | 1/4 | 7/16-20 | 11 | 22.6 | 4.4 | 4F-T | |||||
| 8 | 5/16 | 1/2-20 | 13 | 24.1 | 6 | 5F-T | |||||
| 10 | 3/8 | 9/16-18 | 14 | 26.9 | 7.5 | 6F-T | |||||
| 12 | 1/2 | 3/4-16 | 19 | 31.8 | 9.9 | 8F-T | |||||
| 14/15/16 | 5/8 | 7/8-14 | 22 | 36.8 | 12.3 | 10F-T | |||||
| 18/20 | 3/4 | 11/16-12 | 27 | 42.2 | 15.5 | 12F-T | |||||
| 25 | 1 | 1 5/16-12 | 33 | 46 | 21.5 | 16F-T | |||||
| 28/30/32 | 1 1/4 | 15/8-12 | 41 | 52.3 | 27.5 | 20F-T | |||||
| 35/38 | 1 1/2 | 1 7/8-12 | 48 | 59.2 | 33 | 24F-T | |||||
At Max Tube Fittings, we are the leading supplier, manufacturer, and exporter of Union Cross in Delhi, India. Our state-of-the-art manufacturing facilities, strategically located in the India, empower us to provide high-quality solutions tailored to your specific requirements. With an extensive inventory of various premium materials, we are well-equipped to meet your needs efficiently. Our dedication to excellence and operational efficiency ensures we consistently maintain available stock, making us your trusted partner for reliable Union Cross fittings in various applications.
Max Tube Fittings is a leading supplier and stockist of premium Union Cross in Delhi, India. Our products are widely utilized across various industries, recognized for their strength, durability, and reliable performance in connecting multiple pipe sections. We are committed to delivering exceptional service and ensuring high levels of customer satisfaction. Our advanced manufacturing techniques set us apart in the fittings industry, enabling us to consistently provide top-quality Union Cross fittings while effectively addressing the unique requirements of our customers.
Contact us to get a quick quote for your requirement.
Union Cross Fittings are extensively utilized in applications requiring multi-direction fluid or gas flow, including instrumentation systems, chemical facilities, power plants, nuclear uses, and off-shore platforms. Their structural design facilitates the simple incorporation of complicated tube networks with high-pressure sealing. In pharmaceutical and food-grade applications, they facilitate clean and contamination-free operations. Titanium or zirconium versions in marine and desalination applications are resistant to corrosion from chemicals and brine. They provide uniform performance in laboratory equipment, fuel systems, and hydraulic systems.
Please feel free to contact us if you need any further information or for enquiry.
