Stainless Steel 316 Ball Valve

Home > Stainless Steel >Stainless Steel 316 Ball Valve

Max Tube Fittings is a reliable manufacturer and supplier of Stainless Steel 316 Ball Valves based in Delhi, India. We specialize in providing precision-engineered flow control solutions tailored for critical industries. Our Stainless Steel 316, enhanced with molybdenum, offers exceptional resistance to pitting, crevice corrosion, and harsh chemical environments, far surpassing the standard 304 grade. Designed for durability and leak-proof performance, our SS 316 Ball Valves maintain excellent mechanical strength even under high pressure and temperature. With their smooth operation and sturdy construction, these valves are a go-to choice for industries that demand safety, reliability, and a long service life in challenging fluid and gas handling systems.

Stainless Steel 316 One-Piece Instrumentation Ball Valves Manufacturer in Delhi, Stainless Steel DIN 1.4436 Compression Ball Valve in India, SS UNS S31600 Hydraulic Ball Valve Supplier in Delhi, X5CrNi18-10 Stainless Steel High Pressure Ball Valve Price List in Delhi, 316 Stainless Steel 2 Way Ball Valve Price in India, DIN 1.4436 SS 3 Way Ball Valve in Delhi, India, UNS S31600 Stainless Steel 4 Way Ball Valve Price in Delhi, 316 Stainless Steel 5 Way Ball Valve Supplier in Delhi

Stainless Steel 316 Ball Valves are made up of about 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, along with carefully controlled amounts of carbon, manganese, and silicon. This unique blend gives them remarkable resistance to chlorides, corrosive chemicals, and marine environments. They boast a tensile strength of around 515 MPa, a yield strength of about 205 MPa, and impressive elongation for added toughness and durability. With excellent creep resistance and outstanding performance across a wide temperature range, SS 316 Ball Valves are built to provide reliable, long-lasting service even in aggressive and corrosive settings.

Stainless Steel 316 Ball Valve Specifications

VALVE SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
THREAD	NPT, BSPP, BSPT, JIC, METRIC, UNF
CONNECTION	THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE
FUNCTION	2 WAY, 3 WAY, 4 WAY, 5 WAY,
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI
SEAL RING MATERIAL	PTFE, PVDF, DELRIN, PEEK, GRAPHITE
STANDARD	ISO , DIN , ANSI , API , ASME , AWWA , MSS ,
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL
MEDIA TEMPERATURE	(-120* C TO 500*C )RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK
BRAND NAME	TU-LOK
PACKING DETAILS	BOX PACKING, WOODEN PALLET
EQUIVALENT BRANDS	SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE
APPLICATION	MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS,

Stainless Steel 316 Ball Valve Chemical Composition

Grade		Mn	C	S	Mo	N	Si	P	Cr	Ni
316	Minimum	–	–	–	2.00	–	–	0	16.0	10.0
316	Maximum	2.0	0.08	0.03	3.00	0.10	0.75	0.045	18.0	14.0
316H	Minimum	0.04	0.04	–	2.00	–	0	–	16.0	10.0
316H	Maximum	0.10	0.10	0.03	3.00	–	0.75	0.045	18.0	14.0

Stainless Steel 316 Ball Valve Mechanical Properties

Grade	Yield Strength	Tensile Strength	Elongation (%)	Reduction of Area (%)	Hardness Max
Grade	Min (Mpa)	Min (Mpa)	Min	Min (50mm)	HB
Stainless Steel 316 Valves	170	485	30	50	217*
Stainless Steel 316 Valves	205	515	30	50	217*

Stainless Steel 316 Ball Valve Equivalent

Grade	British		Euronorm		UNS No	SS	JIS
Grade	European Standards	British Standards	DIN No	Name	UNS No	SS	JIS
316	58H, 58J	316S31	1.4401	X5CrNiMo17-12-2	S31600	2347	SUS 316
316H	–	316S51	–	–	S31609	–	–

Top Stainless Steel 316 Ball Valve Manufacturing Company in Delhi

At Max Tube Fittings, we are the largest supplier, manufacturer, and exporter of Stainless Steel 316 Ball Valve in Delhi, India. Our advanced manufacturing facilities, strategically positioned in the India, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Stainless Steel 316 Ball Valve

Stainless Steel 316 Instrumentation Ball Valve Price in Delhi, UNS S31600 Stainless Steel Compression Ball Valve Supplier in Delhi, X5CrNi18-10 Stainless Steel Hydraulic Ball Valve Manufacturer in Delhi, DIN 1.4436 Stainless Steel High Pressure Ball Valve in India, 316 Stainless Steel 2 Way Ball Valve Supplier in Delhi, UNS S31600 Stainless Steel 3 Way Ball Valve in Delhi, India, DIN 1.4436 Stainless Steel 3 Way Ball Valve Price List in Delhi, 316 SS 5 Way Ball Valve Price in India

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Stainless Steel 316 Ball Valve in Delhi, India

Max Tube Fittings is a leading supplier and stockist of premium Stainless Steel 316 Ball Valve in Delhi, India. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Stainless Steel 316 Ball Valves Uses

Stainless Steel 316 Ball Valves find extensive use in industries where top-notch corrosion resistance and durability are crucial. They are commonly utilized in chemical processing, pharmaceuticals, food and beverage, petrochemicals, oil & gas, water treatment, pulp & paper, and marine applications. Their ability to endure chlorides and harsh media makes them particularly well-suited for seawater systems and saline environments. With smooth operation, leak-tight sealing, and a long service life, SS 316 Ball Valves are the preferred choice for fluid and gas control in critical applications.
